Tomei Version 2 Expreme Exhaust Manifold for Nissan 240SX KA24DE 1989-1998 Stainless Steel
Tomei Version 2 Expreme Exhaust Manifold for Nissan 240SX KA24DE 1989-1998 Stainless Steel
Tomei Version 2 Expreme Exhaust Manifold for Nissan 240SX KA24DE 1989-1998 Stainless Steel
Tomei

Tomei Version 2 Expreme Exhaust Manifold for Nissan 240SX KA24DE 1989-1998 Stainless Steel

Regular price $1,530.00 $0.00 Unit price per
Shipping calculated at checkout.

TB601A-NS16B

EXHAUST MANIFOLD EXPREME S13/S14 KA24DE TURBO TYPE Ver.2



The KA24 Turbo Exhaust Manifold is Back– “Refined to Shine, Reinforced to Perform!”

MAKER ENGINE MODEL
NISSAN KA24DE 240SX


Overview

TOMEI USA is proud to announce the re-release of the KA24 Turbo Exhaust Manifold!

We have enhanced materials and manufacturing while preserving the original design, achieving greater durability, performance, and a sleek appearance.
Since its launch in 2015, this manifold has earned high praise from 240SX S13/S14 owners.
Designed for seamless compatibility with SR20 components, it enables efficient turbocharging for KA24 engines, delivering a significant performance boost.
However, due to mold deterioration, production was discontinued in 2022.
Now, after three years of development, it returns with major refinements.
We upgraded from cast iron to high-quality stainless steel, using advanced lost-wax casting for superior durability, heat resistance, and easier installation.
Optimized for the KA24’s long-stroke design, this manifold delivers smooth, torque-rich power, excelling in both daily driving and high-performance applications.
We appreciate your patience and support. This is our best version yet, and we hope all KA24 enthusiasts will enjoy its benefits.
Unlock the full potential of Nissan’s KA24 engine with this advanced turbocharging solution!


SPEC

MATERIAL Austenitic Ductile Cast iron
LAYOUT 4-2-1
PIPE THICKNESS 5.0mm
PIPE DIAMETER INT I.D 40.0mm(Approx.)
OUT I.D 48.6mm(Approx.)
FLANGTE THICKNESS F 13.0mm
R 14.0mm
FLANGE TYPE R -
R T25
WEIGHT 5.6kg
